CGS Hawk PLUS

Cargo single-seater

PLUS Ultralight

While the single seat Hawk Classic and Arrow models have large baggage areas behind the seat, it can be difficult to place large bulky items back there. The Plus was designed to accommodate the requests of customers needing a larger cargo capacity. The Hawk Plus uses the same fuselage as the two seat Arrow, but with only the front seat. Wing tanks are standard on the Plus, so the rear area is completely unobstructed for hauling cargo, additional fuel tanks, or a passenger in a jump seat. We have put four large filled duffle bags on board and still had room for the small stuff. With the larger engine options offered, up to 250 lbs. can be carried in the rear baggage area.

Another feature of the Hawk Plus is the wing spars, which are stronger than those found on standard single seat models. They are 2 1/4" dia. X .083 (instead of .049) wall thickness to provide the same load factors as the single place models. The Hawk Plus also has the semi symmetrical wing, streamline struts, reinforced boom, wing tanks, fiberglass nose cone, folding tail, and curved overhead and windshield as standard equipment.

Numbers

Specifications — Hawk PLUS

Empty Weight 350lbs
Gross Weight 800lbs
Wing Span 29'
Wing Area 135 sq. ft
Engine Size 40-65 hp
Rate of Climb 800-1100 fpm
Cruise Speed 60-80 mph
Stall Speed 35-40 mph
Vne 100 mph
Assembly Time for First time Builder 250 hours

What’s in the box

Basic kit includes as standard equipment

Airframe
3-Position Wing Flaps (not flaperons)
Reinforced boom tube
Full fuselage pilot surround (roll cage)
Heavy duty wing frames, 2 ¼” front spar, 1 ¾” rear spar (factory pre-built)
Seat belt with shoulder harness
All control surfaces (factory pre-built) (flaps, ailerons, rudder, vertical stab,horizontal stab, & elevator)
Heavy duty fiberglass landing gear legs
Your choice – tail dragger with steerable tail wheel or tricycle/steerable nosewheel
Large rear doors to accommodate bulky items transported in cargo area
Streamlined struts – aluminum
Streamlined landing gear fairings
Curved overhead carry through increases head room by 3”
Folding tail
Lower rib battens (for semi-symmetrical wing)
Fiberglass nose cone - adds 3-4 mph to top speed, provides streamlined appearance
Rough terrain wheels - 16" x 6.5" x 6"
2 five gallon wing tanks
Anodized tubing

Price

*All domestic kits shipped via truck line are subject to a crating charge per kit. Orders which are picked up at the factory are not subject to the crating charge

Colors

Covering Package & Colors

Includes your choice of either 3.8 oz. stabilized dacron covers or dope and fabric kit. Dacron covers include all control surfaces which are pre sewn and ready to install, zipper doors, and full fuselage enclosure. Dope and fabric kit includes ribs, stringers, hard doors, fabric, and glue - everything but paint).

**There is no extra charge for ordering Dacron covers with solid colors. You can mix the solid colors as much as you like. (i.e. red wings, yellow ailerons, yellow flaps, black fuselage, etc.). Stripes and special logos are optional, and a layout diagram needs to be submitted for a quote. Color samples and layout diagrams are available upon request.

Power

Engine Packages* — Hawk PLUS

* Engine packages offered below are for combining with the above kit and covering packages only

** Due to the varying rate of the Euro against the US Dollar, all engine packages will be priced at the time written order is received. Ask via the contact form for current pricing.

Rotax 447 (40 h.p.) Engine Package:

Includes engine, IVO two blade prop, throttle assembly, motor mounts, muffler mounts, miscellaneous hardware and brackets

Rotax 503 (50 h.p.) Dual Carb Engine Package:

Includes engine, IVO two blade prop, throttle assembly, motor mounts, muffler mounts, miscellaneous hardware and brackets

Rotax 582 (65 h.p.) Engine Package:

Includes engine, radiator package, IVO three blade prop, electric start, throttle assembly, motor mounts, muffler mounts, miscellaneous hardware and brackets.

HKS 700E 4 Stroke (65 h.p.) Engine Package:

Includes engine, electric start, IVO three blade prop, throttle assembly, motor mounts, muffler mounts, miscellaneous hardware, and brackets.

Add-ons

Additional Options for Hawk PLUS

Trim Tab (in cockpit adjustable)
Brakes, mechanical
Brakes, hydraulic O’Brien w/stick mounted master cylinder
Brakes, hydraulic Hager w/stick mounted master cylinder, includes Hager wheels
Wing/Tail folding Package
Folding Tail Only
Hard Doors for Single Place (2 doors) applies only to Dacron orders
Map case in doors for storing sectionals, etc. (per door – cloth door only)
Tinted Lexan Windows
Wing Window Tinted

BRS

Parachute Options for Hawk PLUS (Includes CGS Mounting Package)

BRS 600 (600 lbs.) Softpack
BRS 800 (800 lbs.) Softpack
BRS 1050 (1050 lbs.) Softpack
BRS 1050 (1050 lbs.) Canister
BRS 1050 (1050 lbs.) VLS
Freight for parachute systems

More

Special Options

Fast-build kit, requires only 150 hours to complete (for first time builder)
Special crating for fast-build kit - Market
Amphibious and standard Float Systems available.
Wing tank kit, 10 gal total (5 gal per side) Includes 2 tanks, hoses, fittings,sump tank, mounting brackets, straps, etc.
Wheel pants (pants only), Set of 3
Wheel pants (pants only), Set of 2
Wheel pants mounting kit
